Description
The AMD Ryzen 5 8500G is part of the AMD Ryzen 5 8000 G-Series desktop processor lineup with integrated Radeon Graphics, combining capable CPU performance with strong onboard graphics for a complete computing solution. Featuring a hybrid architecture of 2 Zen4 and 4 Zen4c cores, this AM5 socket processor totals 6 cores and 12 threads, making it well suited for everyday computing, light gaming, and multimedia tasks without a discrete graphics card. The integrated Radeon 740M graphics support up to 4 displays, DisplayPort 2.1, HDMI 2.1, and AMD FreeSync, while AMD EXPO memory overclocking and Precision Boost Overdrive give users flexibility to tune performance. With DDR5 memory support, USB4 connectivity, and broad video encode and decode capability, this processor offers a versatile, efficient platform for compact and mainstream desktop builds.
Features
- 6 cores and 12 threads with hybrid 2x Zen4 and 4x Zen4c architecture
- Boost clock speeds of up to 5.0GHz with Zen4c cores boosting up to 3.7GHz
- Integrated AMD Radeon 740M Graphics with 4 graphics cores and 2800 MHz frequency
- Supports up to 4 displays with DisplayPort 2.1 and HDMI 2.1 output
- AMD FreeSync support along with Adaptive-Sync and HDR Metadata for smooth visuals
- Supports AMD EXPO memory overclocking technology for enhanced DDR5 performance
- Precision Boost Overdrive and Curve Optimizer Voltage Offsets for performance tuning
- Compatible with AMD Ryzen Master software for streamlined performance control
- USB4 (40Gbps) connectivity along with USB 3.2 Gen 2 and USB 2.0 ports
- PCIe 4.0 support with NVMe Boot, RAID0, and RAID1 capability
- Wireless display support via Miracast and AMD SmartAccess Memory
- AMD Enhanced Virus Protection (NX bit) for added system security
Specifications
General Specifications
- Platform: Desktop
- Product Family: AMD Ryzen Processors
- Product Line: AMD Ryzen 5 8000 G-Series Desktop Processors with Radeon Graphics
- AMD PRO Technologies: No
- Consumer Use: Yes
- Regional Availability: Global
- Former Codename: Phoenix
- Architecture: 2 x Zen4, 4 x Zen4c
- Number of CPU Cores: 6
- Multithreading (SMT): Yes
- Number of Threads: 12
- Max. Boost Clock: Up to 5.0GHz
- Max Zen4c Clock: Up to 3.7GHz
- Base Clock: 3.5GHz
- Zen4 Base Clock: 4.1GHz
- Zen4c Base Clock: 3.2GHz
- L2 Cache: 6MB
- L3 Cache: 16MB
- Default TDP: 65W
- AMD Configurable TDP (cTDP): 45-65W
- Processor Technology for CPU Cores: TSMC 4nm FinFET
- CPU Compute Die (CCD) Size: 137mm2
- Package Die Count: 1
- AMD EXPO Memory Overclocking Technology: Yes
- Precision Boost Overdrive: Yes
- Curve Optimizer Voltage Offsets: Yes
- AMD Ryzen Master Support: Yes
- CPU Socket: AM5
- CPU Boost Technology: Precision Boost 2
- Instruction Set: x86-64
- Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
- Max. Operating Temperature (Tjmax): 95C
- OS Support: Windows 11 64-Bit Edition, Windows 10 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit (OS support will vary by manufacturer)
Connectivity
- Native USB4 (40Gbps) Ports: 2
- Native USB 3.2 Gen 2 (10Gbps) Ports: 2
- Native USB 2.0 (480Mbps) Ports: 1
- PCI Express Version: PCIe 4.0
- Native PCIe Lanes (Total/Usable): 14/10
- NVMe Support: Boot, RAID0, RAID1
- System Memory Type: DDR5
- Memory Channels: 2
- Max. Memory: 256GB
- System Memory Subtype: UDIMM
- Max Memory Speed: 2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600
Graphics Capabilities
- Integrated Graphics: Yes
- Graphics Model: AMD Radeon 740M
- Graphics Core Count: 4
- Graphics Frequency: 2800 MHz
- DirectX Version: 12
- DisplayPort Version: 2.1
- DisplayPort Extensions: HDR Metadata, Adaptive-Sync, UHBR10
- DisplayPort Max Refresh Rates (SDR): 7680x4320@60Hz, 3840x2160@240Hz, 3440x1440@360Hz, 2560x1440@480Hz, 1920x1080@600Hz
- DisplayPort Max Refresh Rates (HDR): 7680x4320@60Hz, 3840x2160@240Hz, 3440x1440@360Hz, 2560x1440@480Hz, 1920x1080@600Hz
- HDMI Version: 2.1
- HDCP Version Supported: 2.3
- USB Type-C DisplayPort Alternate Mode: Yes
- Multi-Monitor Support: Yes
- Max Displays: 4
- AMD FreeSync: Yes
- Wireless Display: Miracast
- AMD SmartAccess Memory: Yes
Security, Virtualization, and Manageability
- AMD Enhanced Virus Protection (NX bit): Yes
