Description
Powered by AMD's advanced Zen 4 architecture, the Ryzen 7 7700 desktop processor delivers exceptional performance for gaming, content creation, and everyday computing. Built on the AM5 socket platform, this 8 core, 16 thread processor combines high boost clocks with integrated AMD Radeon Graphics, giving users a capable all-in-one solution without the immediate need for a discrete graphics card. Support for DDR5 memory, PCIe connectivity, and AMD EXPO overclocking technology ensures the platform is ready for demanding workloads today while remaining upgradable for future AMD Socket AM5 innovations. Backed by the included AMD Wraith Prism cooler, this processor is designed to keep systems running efficiently under sustained performance.
Features
- 8 cores and 16 threads built on TSMC 5nm Zen 4 architecture for CPU cores
- Boost clock speeds of up to 5.3GHz for fast, responsive performance
- Integrated AMD Radeon Graphics with 2 graphics cores for display output without a discrete GPU
- Unlocked for overclocking with Precision Boost Overdrive and Curve Optimizer Voltage Offsets
- Supports AMD EXPO memory overclocking technology for enhanced DDR5 performance
- Compatible with AMD Ryzen Master software for easy performance tuning
- AM5 socket support with compatibility across X670E, X670, B650E, and B650 chipsets
- Supports DDR5 UDIMM memory with speeds up to DDR5-5200/3600 depending on configuration
- USB Type-C support with native USB 3.2 Gen 2 and DisplayPort Alternate Mode
- NVMe support including Boot, RAID0, RAID1, and RAID10 configurations
- Includes AMD Wraith Prism thermal solution for efficient cooling
- Default TDP of 65W for balanced power efficiency and performance
Specifications
General Specifications
- Platform: Desktop
- Market Segment: Enthusiast Desktop
- Product Family: AMD Ryzen Processors
- Product Line: AMD Ryzen 7 Processors
- AMD PRO Technologies: No
- Consumer Use: Yes
- Regional Availability: Global
- Former Codename: Raphael AM5
- Architecture: Zen 4
- Number of CPU Cores: 8
- Multithreading (SMT): Yes
- Number of Threads: 16
- Max. Boost Clock: Up to 5.3GHz
- Base Clock: 3.8GHz
- L1 Cache: 512KB
- L2 Cache: 8MB
- L3 Cache: 32MB
- Default TDP: 65W
- Processor Technology for CPU Cores: TSMC 5nm FinFET
- Processor Technology for I/O Die: TSMC 6nm FinFET
- CPU Compute Die (CCD) Size: 71mm2
- I/O Die (IOD) Size: 122mm2
- Package Die Count: 1
- Unlocked for Overclocking: Yes
- AMD EXPO Memory Overclocking Technology: Yes
- Precision Boost Overdrive: Yes
- Curve Optimizer Voltage Offsets: Yes
- AMD Ryzen Master Support: Yes
- CPU Socket: AM5
- Supporting Chipsets: X670E, X670, B650E, B650
- CPU Boost Technology: Precision Boost 2
- Instruction Set: x86-64
- Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
- Thermal Solution (PIB): AMD Wraith Prism
- Max. Operating Temperature (Tjmax): 95C
- Launch Date: 1/14/2023
- OS Support: Windows 11 64-Bit Edition, Windows 10 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit (OS support will vary by manufacturer)
Connectivity
- USB Type-C Support: Yes
- Native USB 3.2 Gen 2 (10Gbps) Ports: 4
- Native USB 3.2 Gen 1 (5Gbps) Ports: 0
- Native USB 2.0 (480Mbps) Ports: 1
- Native SATA Ports: 0
- Native PCIe Lanes (Total/Usable): 28/24
- Additional Usable PCIe Lanes from Motherboard: X670E 12x Gen4, X670 12x Gen4, B650E 8x Gen4, B650 8x Gen4
- NVMe Support: Boot, RAID0, RAID1, RAID10
- System Memory Type: DDR5
- Memory Channels: 2
- System Memory Subtype: UDIMM
- Max Memory Speed: 2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600
- ECC Support: Yes (Requires motherboard support)
Graphics Capabilities
- Integrated Graphics: Yes
- Graphics Model: AMD Radeon Graphics
- Graphics Core Count: 2
- Graphics Frequency: 2200 MHz
- GPU Base: 400 MHz
- USB Type-C DisplayPort Alternate Mode: Yes
Features
- Supported Technologies: AMD EXPO Technology, AMD Ryzen Technologies
