Description
This 23.8 inch Full HD display features an IPS panel with a wide viewing angle, a 120Hz refresh rate and a 1ms response time in a 3-side frameless design. The IPS panel delivers 178 degree horizontal and vertical viewing angles while maintaining consistent image quality and colours from all viewing positions. It supports a resolution of 1920x1080 at 100Hz over HDMI and 1920x1080 at 60Hz over VGA, includes built-in speakers and an earphone output, and offers a 100mm x 100mm VESA wall-mount pattern.
Features
- IPS Panel: 178 degree horizontal and vertical viewing angles with consistent image quality and colours
- Full HD Resolution: 1920x1080 at 100Hz over HDMI and 1920x1080 at 60Hz over VGA
- 120Hz Refresh Rate: smooth visuals
- 1ms Response Time: fast response
- 3-Side Frameless Design: ultra slim profile
- Flicker Free
- Built-in Speakers: 2W x 2
- Earphone Output
- VESA Wall-Mount Compatible: 100mm x 100mm
Specifications
- Panel: 23.8" IPS
- Pixel Pitch: 0.2745 (H) x 0.2745 (V) mm
- Effective Viewing Area: 527.04 (H) x 296.46 (V) mm
- Brightness (Typical): 250 cd/m²
- Contrast Ratio: 1300:1 (Typical), 20 Million:1 (DCR)
- Response Time: 4ms GtG / 1ms MPRT
- Viewing Angle: 178° (H) / 178° (V) (CR > 10)
- Colour Gamut: NTSC 83% (CIE1976) / sRGB 100% (CIE1931)
- Optimum Resolution: 1920 x 1080 at 100Hz (HDMI), 1920 x 1080 at 60Hz (VGA)
- Display Colours: 16.7 Million
- Signal Input: VGA x 1, HDMI 1.4 x 1
- USB Hub: No
- Power Supply: 100 - 240V, 1.5A, 50 / 60Hz
- Power Consumption (Typical): 30W
- Speakers: 2W x 2
- Line in and Earphone: Earphone x 1
- Wall-Mount: 100mm x 100mm
- Adjustable Stand: Tilt -5° to 23°
- Product without Stand: 316.2 (H) x 542.4 (W) x 44.6 (D) mm
- Product with Stand: 412.1 (H) x 542.4 (W) x 202.3 (D) mm
- Packaging: 394 (H) x 614 (W) x 126 (D) mm
- Product without Stand Weight: 2.65kg
- Product with Stand Weight: 2.97kg
- Product with Packaging Weight: 4.65kg
- Cabinet Colour: Black
- Regulatory Approvals: CE / FCC / RoHS
Package Contents
- 1x AOC 23.8 Inch IPS Office Monitor
- 1x HDMI Cable 1.8m
