The ASUS DC500 Triple 4K Thunderbolt 4 Dock expands a single Thunderbolt 4 connection into a full desktop workstation, supporting up to three external displays for multi-monitor productivity. A single Thunderbolt 4 port pairs with two HDMI 2.1 outputs to drive resolutions as high as 7680x4320 at 30Hz over Thunderbolt or 3840x2160 at 60Hz over HDMI, giving users flexibility for both high-resolution work and everyday multitasking. The dock rounds out connectivity with SD and Micro SD card readers, USB-A 3.2 Gen2 and USB-A 2.0 ports, 2.5GbE networking, an audio combo jack, and a Kensington lock slot for physical security, all built into a compact black metal-and-plastic housing. A 150W power adapter keeps connected devices charged, and the bundled 80cm cable keeps the setup tidy on a desk.
-
Single Thunderbolt 4 port with dual HDMI 2.1 outputs
-
Supports up to three external displays
-
Resolutions up to 7680x4320@30Hz over Thunderbolt 4
-
HDMI output up to 3840x2160@60Hz
-
SD and Micro SD card readers (UHS-II)
-
USB-A 3.2 Gen2 and USB-A 2.0 ports
-
2.5GbE RJ45 networking port
-
Audio combo jack for headset connectivity
-
Kensington lock slot for security
-
Power button with indicator LED
-
Compatible with Windows 10+ and macOS 12.3+
-
Includes 150W power adapter
-
Category: Dock
-
I/O Ports: 1 x Thunderbolt 4, 2 x HDMI 2.1, 1 x SD card reader 4.0 (UHS-II), 1 x Micro SD card reader (UHS-II), 2 x USB-A 3.2 Gen2, 2 x USB-A 2.0, 1 x RJ45 2.5GbE, 1 x audio combo jack, 1 x Kensington lock, 1 x power button with indicator LED, 1 x DC jack (4.5phi)
-
Video Resolution: Supports multiple HDMI single extension outputs up to 3840x2160@60Hz; Thunderbolt 4 extension outputs up to 7680x4320@30Hz and 3840x2160@60Hz
-
OS Support: Windows 10 or later, macOS 12.3 or later
-
Power Adapter: 150W, DC20.0V/7.5A
-
Security: Kensington lock
-
Cable Length: 80cm
-
Colour: Black
-
Weight: 335g
-
Dimensions: 185 x 80 x 21mm
-
Material: Plastic
