Description:
The CyberPower UPS guarantees power protection for computers, networking equipment, and storage devices. The product adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output. The patented GreenPower UPS™ Bypass design achieves ultra-low power consumption to reduce energy costs and allows a lower operation temperature which extends battery lifespan. The LED indicator shows the utility, battery, and operating status of the UPS, and it is also compatible with generators to extend power continuity. Other capabilities include overload protection, EMI filter, and configurable alarm to safeguard your devices, while its tower design allows users to place it easily on desks or other tight spaces.
Features:
- Line-interactive UPS topology
- Automatic Voltage Regulation (AVR)
- LED status indicator
- Surge and spike protection
- High-speed Ethernet data transmission
- PowerPanel management software
- EMI and RFI filtration
- Energy Saving Technology
- Generator compatible
- Overload protection
- Phone, fax, modem, DSL, and network protection
- USB connectivity port
- Configurable alarm
Specifications:
- Brand: CyberPower
- Series: UT
- Phase: Single phase
- Form factor: Tower
- UPS topology: Line-interactive
- Energy saving technology: GreenPower UPS™ Bypass Technology
- Generator compatibility: Yes
- Nominal input voltage: 230 ± 10% Vac
- Input voltage range: 165 ~ 290 Vac
- Input frequency: 50 ± 5 Hz, 60 ± 5 Hz
- Input frequency detection: Auto-sensing
- Rated input current: 3.69 A
- Input connector type: Schuko
- Power cord length: 4 ft (1.2 m)
- Capacity: 850VA / 425W
- On battery waveform: Simulated sine wave
- On battery voltage: 230 ± 10% Vac
- On battery frequency: 50 ± 1%, 60 ± 1% Hz
- AVR: Single boost, single buck
- Overload protection: Internal current limiting, fuse
- Total outlets: 3 (Schuko x 3)
- Battery and surge protected outlets: 3
- Typical transfer time: 4 ms
- Runtime at 60W: 30 min
- Runtime at 90W: 20 min
- Runtime at 200W: 6 min
- Typical recharge time: 6 hours
- Start on battery: Yes
- User-replaceable battery: No
- Battery type: Sealed lead-acid
- Surge suppression: 125 Joules
- EMI/RFI filtration: Yes
- Phone/network protection: RJ11/RJ45 (Combo), 1-in, 1-out
- LED indicators: Power on, line mode, battery mode, bypass mode, low battery, overload, UPS fault
- HID compliant USB port: 1
- Audible alarms: Battery mode, low battery, overload, UPS fault
- Ethernet data transmission speed: Up to 1Gbps
- Power management software: PowerPanel Personal (recommended)
- Enclosure construction: Plastic
- Colour: Black
- Dimensions (WxHxD): 84 x 174 x 280 mm (3.31 x 6.85 x 11.02 in)
- Weight: 4.2 kg (9.26 lbs)
- Operating temperature: 0 ~ 40°C (32 ~ 104°F)
- Operating relative humidity (non-condensing): 0 ~ 90%
- Operating elevation: 0-9,843 feet (0-3,000 meters)
- Storage temperature: -20 ~ 50°C (-4 ~ 122°F)
- Storage relative humidity (non-condensing): 0 ~ 90%
- Storage elevation: 0-9,843 feet (0-3,000 meters)
- Online thermal dissipation: 34 BTU/hr
- Certifications: CE
- RoHS: Yes
Package contents:
UPS
Product registration card
Quick start guide
