Description:
The TP-Link TL-SL1311MP is a fanless desktop switch featuring eight 10/100 Mbps PoE+ ports, two Gigabit RJ45 ports and one Gigabit SFP port. It supports IEEE 802.3af/at compliant powered devices and provides up to 30W per PoE port with a total PoE power budget of 124W. Extend Mode enables data and power transmission up to 250m, while Isolation Mode helps separate client traffic for improved security and performance. PoE Auto Recovery automatically reboots dropped or unresponsive powered devices, and the plug-and-play design requires no configuration.
Features:
- 8 × 10/100 Mbps RJ45 PoE+ ports
- 2 × Gigabit RJ45 ports
- 1 × Gigabit SFP port
- Supports IEEE 802.3af/at compliant powered devices
- Up to 30W PoE power per port
- Up to 124W total PoE power for 8 ports
- Extend Mode supports up to 250m PoE power and data transmission
- Isolation Mode separates client traffic
- PoE Auto Recovery automatically reboots dropped or unresponsive devices
- Fanless design for silent operation and reduced power consumption
- Plug-and-play operation with no configuration required
- Auto Negotiation
- Auto MDI/MDIX
- Physical security lock
Specifications:
- Brand: TP-Link
- Product type: PoE+ desktop switch
- Interfaces: 8 × 10/100 Mbps PoE+ RJ45, 2 × Gigabit RJ45, 1 × Gigabit SFP
- Network standards: IEEE 802.3af/at
- Transmission method: Store-and-forward
- Network media: 10BASE-T and 100BASE-TX
- Packet forwarding rate: 5.6544 Mpps
- Switching capacity: 7.6 Gbps
- MAC address table: 2K
- Jumbo frame: 16 KB
- External power supply: 53.5VDC / 2.43A
- Fan quantity: Fanless
- Dimensions: 209 × 126 × 26 mm
- Maximum power consumption: 5.95W with no PD connected; 140.92W with 124W PD connected
- Maximum heat dissipation: 20.29 BTU/h with no PD connected; 480.54 BTU/h with 124W PD connected
- Cable distance: Up to 100m for standard network transmission
- Extend Mode: Ports 1–4 and Ports 1–8, up to 250m PoE power and data transmission
Package Contents:
1 x TP-Link TL-SL1311MP PoE+ Desktop Switch
