Description:
The Intel Core Ultra 5 245KF is a 14-core, 14-thread unlocked desktop processor built on Intel's advanced N3B lithography, combining 6 performance cores with 8 efficient cores for strong multitasking and single-thread performance alike.
Features:
- Unlocked multiplier for CPU overclocking flexibility
- Maximum turbo frequency up to 5.2GHz with 24MB Intel Smart Cache
- Intel AI Boost NPU delivering 13 TOPS Int8 for on-device AI acceleration
- Supports DDR5 memory up to 6400 MT/s across dual channels
- Intel Thunderbolt 4 connectivity for fast peripheral and display support
- Advanced security features including Control-Flow Enforcement, AES New Instructions, and VT-x/VT-d support
Specifications:
- Total Cores: 14 (6 Performance, 8 Efficient)
- Total Threads: 14
- Max Turbo Frequency: 5.2GHz
- Performance-core Max Turbo Frequency: 5.2GHz
- Efficient-core Max Turbo Frequency: 4.6GHz
- Performance-core Base Frequency: 4.2GHz
- Efficient-core Base Frequency: 3.6GHz
- Cache: 24MB Intel Smart Cache
- Total L2 Cache: 26MB
- Processor Base Power: 125W
- Maximum Turbo Power: 159W
- CPU Lithography: TSMC N3B
- Launch Date: Q4'24
- Max Memory Size: 192GB
- Memory Types: Up to DDR5 6400 MT/s
- Maximum Memory Speed: 6400MHz
- Max Memory Channels: 2
- NPU: Intel AI Boost, 13 TOPS Int8, sparsity and Windows Studio Effects support
- Direct Media Interface (DMI) Revision: 4
- Max DMI Lanes: 8
- Intel Thunderbolt 4: Yes
- PCI Express Revision: 5.0 and 4.0
- PCI Express Configurations: Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
- Max PCI Express Lanes: 24
- Socket Supported: FCLGA1851
- Thermal Solution Specification: PCG 2020A
- Max Operating Temperature: 105°C
- Intel Turbo Boost Technology: 2.0
- Instruction Set: 64-bit
- Instruction Set Extensions: Intel SSE4.1, SSE4.2, Intel AVX2
- Security Features: Standard Manageability (ISM), Control-Flow Enforcement Technology, AES New Instructions, Secure Key, Trusted Execution Technology, Execute Disable Bit, OS Guard, Boot Guard, Mode-based Execute Control, VT-x, VT-d, VT-x with EPT
