Description
The Ubiquiti Door Closer is a mechanical door closer that ensures controlled closure for safety and convenience. It offers an adjustable power size of EN 2 to 6, along with adjustable closing and latching speed and adjustable opening (back check) speed for precise control. The surface mount design with non handed installation supports standard door mounting on the pull side, top jamb mounting on the push side, and parallel arm bracket mounting on the push side for sizes 1 to 5.
Features
- Adjustable power size EN 2 to 6
- Adjustable closing and latching speed
- Adjustable opening (back check) speed
- Surface mount
- Non handed installation
Specifications
- Dimensions: 328 x 88.6 x 53.5 mm (12.9 x 3.5 x 2.1 inches)
- Weight: 3.3 kg (7.3 lb)
- Maximum door size standard door/top jamb mount: 30 inches (762 mm) Size 1 interior / Size 3 exterior; 36 inches (914 mm) Size 2 interior / Size 4 exterior; 42 inches (1067 mm) Size 3 interior / Size 5 exterior; 48 inches (1219 mm) Size 4 interior / Size 6 exterior
- Maximum door size parallel arm bracket mount: 30 inches (762 mm) Size 1 interior / Size 3 exterior; 36 inches (914 mm) Size 2 interior / Size 4 exterior; 42 inches (1067 mm) Size 3 interior / Size 5 exterior; 48 inches (1219 mm) Size 4 interior
- Application range: Standard door mount on the pull side, top jamb mount on the push side, parallel arm bracket mount on the push side (Size 1 to 5 only)
- Power size: 1 to 6
- Certifications: UL 228, UL 10C, ANSI/BHMA A156.4-(2019) Grade 1, ANSI A117.1 ADA
Note: For installation assistance, you can contact us or reach out directly to the brand.
Package Contents
