Description:
The G3 Reader is a compact third generation access reader that supports Touch Pass through Apple Wallet and Google Wallet. It offers NFC card and keyfob access, UniFi Identity mobile access, and handwave request to exit functionality, powered via PoE using the UniFi Control Hub.
Note: For installation assistance, you can contact us or reach out directly to the brand.
Features:
- Handwave request to exit
- Outdoor ready design
- Powered via PoE using UniFi Control Hub
- Slim, modern profile with IP55 weatherproofing suited for indoor and covered outdoor installations
Specifications:
- Colour: White
- Dimensions: 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
- NFC Card and Keyfob Access: Yes
- Apple/Google Wallet: Yes
- Mobile Unlock: Yes
- Handwave Request to Exit: Yes
- NDAA Compliant: Yes
- UL 294 Level: Destructive attack Level I, Line security Level I, Endurance Level I, Standby power Level I
- Weatherproofing: IP55
- Weight: 82 g (2.9 oz)
- Enclosure Material: Polycarbonate, glass
- Mount Material: Aluminium alloy
- Mounting: In-wall, gang box (included), junction box (optional)
- Indoor and Outdoor Use: Yes
- Ambient Operating Temperature: -30 to 45°C (-22 to 113°F)
- Ambient Operating Humidity: 5 to 90% noncondensing
- Networking Interface: One 10/100 MbE RJ45 port
- Connectivity: BLE 4.1, NFC
- Power Method: PoE, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
- Maximum Power Consumption: 5W
- Supported Voltage Range: 48V DC
- ESD/EMP Protection: Air ±15kV, contact ±8kV
- Sensors: Proximity sensor
- Speaker: One, 0.7W
- LEDs: R/G/B/W
- Button: One factory reset button
- NFC Frequency: 13.56 MHz
- NFC Read Range: Less than 30 mm
- NFC Technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340), MIFARE Classic, MIFARE DESFIRE, Sony FeliCa (ID only), NFC Forum tags T1T, T2T, T3T, T4T and T5T, ECP 2.0
- PoE Cabling Requirements: Cat 5e cabling is the minimum performance category recommended, matched to the transmission speed required at the installation site. Minimum conductor gauge is 26 AWG (0.13 mm²) for patch cords and 24 AWG (0.21 mm²) for horizontal or riser cable
- UL 294 Statement: Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits
- CAN/ULC-60839-11-1 Grade: Grade assignment I
- Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
- Management Application: Access
