Description
The Ubiquiti U7 Lite is a compact, ceiling mounted WiFi 7 access point with 4 spatial streams and a 2.5 GbE uplink. This ultra compact, highly capable access point comes in at an incredible price point, making top tier connectivity more accessible than ever before. Built for large scale deployments and powered by Ubiquiti's continuously evolving UniFi software engine, the U7 Lite is fully equipped with advanced WiFi 7 features like preamble puncturing to avoid 5 GHz interference and MLO for ultra low client latency. It is designed to support a high number of simultaneous client connections without compromising performance, with advanced WiFi 7 technology ensuring wider coverage and stronger signal stability for seamless connectivity across homes, offices, and small businesses. Covering 115 m² (1,250 ft²) and supporting over 200 connected devices, it is powered using PoE with a Lite Mount included for ceiling and wall installation.
Features
- WiFi 7
- 4 spatial streams
- 115 m² (1,250 ft²) coverage
- 200+ connected devices
- Powered using PoE
- 2.5 GbE uplink
- Preamble puncturing to avoid 5 GHz interference
- MLO for ultra low client latency
Specifications
- Dimensions: Ø171.5 x 33 mm (Ø6.8 x 1.3 inches)
- WiFi standard: WiFi 7
- Spatial streams: 4
- Coverage area: 115 m² (1,250 ft²)
- Maximum client count: 200+
- Uplink: 2.5 GbE
- Mounting: Ceiling, wall (Lite Mount included)
- Power method: PoE
- MIMO: 5 GHz 2 x 2 (DL/UL MU-MIMO), 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
- Maximum data rate: 5 GHz 4.3 Gbps (BW240), 2.4 GHz 688 Mbps (BW40)
- Antenna gain: 5 GHz 5 dBi, 2.4 GHz 4 dBi
- Maximum TX power: 5 GHz 24 dBm, 2.4 GHz 23 dBm
- Maximum BSSIDs: 8 per radio
- Supported data rates: 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps, 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps, 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps, 802.11n 6.5 Mbps to 300 Mbps
- Features: Wireless meshing, band steering, 802.11v BSS transition management, 802.11r fast roaming, 802.11k radio resource management, advanced radio management, Passpoint (Hotspot 2.0), captive hotspot portal with custom branding landing page, voucher authentication, payment based authentication, external portal server support, password authentication, guest network isolation, private pre shared key (PPSK), WiFi speed limiting, client device isolation, WiFi schedules, RADIUS over TLS (RadSec), dynamic RADIUS assigned VLAN
- Maximum power consumption: 13W
- Supported voltage range: 42.5 to 57V DC
- Networking interface: 1 x 2.5 GbE RJ45 port
- Weight: 313 g (11 oz)
- Management: Ethernet
- Enclosure material: UV stabilised polycarbonate
- Mount material: UV stabilised polycarbonate, galvanised steel (SGCC)
- LEDs: System white/blue
- Channel bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
- Certifications: CE, FCC, IC
- NDAA Compliant: Yes
- Ambient operating temperature: -30 to 40° C (-22 to 104° F)
- Ambient operating humidity: 5 to 95% noncondensing
- Application requirements: UniFi Network version 9.0.114 and later, UniFi OS iOS version 10.20.2 and later, Android version 10.21.7 and later
Note: For installation assistance, you can contact us or reach out directly to the brand.
Package Contents
- Ubiquiti U7 Lite Access Point
- Lite Mount
