Description
The Ubiquiti U7 Pro XG is a ceiling mounted 6 stream WiFi 7 access point with 10/5/2.5/1 GbE support. From the inside out, every mechanical and electronic detail has been meticulously shaped to strike the perfect balance between aesthetics and performance, with a new thermal architecture enabling the sleekest form factor ever while preserving the timeless look that UniFi fans know and love. Ideal for most network environments, it delivers robust performance with the latest WiFi 7 capabilities, including MLO and 3+ Gbps client performance. The U7 Pro XG is equipped with 10 GbE ports to expose the performance potential of WiFi 7, as clients become more capable and single clients reach throughput of 3+ Gbps. Covering up to 140 m² (1,500 ft²) and supporting over 300 connected devices, it features a 6 GHz radio and is powered using PoE+. For the first time, the U7 Pro XG comes in dual colour options, white and a new black variant, allowing it to blend seamlessly into any interior design. If you are looking to modernise your network with top tier performance and a timeless yet modern look, the U7 Pro XG ushers you into the new era of WiFi: low latency, high speed, and a true wired experience without the cables.
Features
- 6 spatial stream WiFi 7 with 6 GHz support
- Up to 140 m² (1,500 ft²) coverage
- 300+ connected devices
- 6 GHz radio
- 10/5/2.5/1 GbE uplink
- Powered using PoE+
- Latest WiFi 7 capabilities including MLO and 3+ Gbps client performance
- Sleek form factor with new thermal architecture
Specifications
- Dimensions: Ø206 x 32.5 mm (Ø8.1 x 1.3 inches)
- WiFi standard: WiFi 7
- Spatial streams: 6
- Coverage area: 140 m² (1,500 ft²)
- Maximum client count: 300+
- Uplink: 10 GbE
- Mounting: Ceiling, wall (Lite Mount included)
- Power method: PoE+
- MIMO: 6 GHz 2 x 2 (DL/UL MU-MIMO), 5 GHz 2 x 2 (DL/UL MU-MIMO), 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
- Maximum data rate: 6 GHz 5.8 Gbps (BW320), 5 GHz 4.3 Gbps (BW240), 2.4 GHz 688 Mbps (BW40)
- Antenna gain: 6 GHz 6 dBi, 5 GHz 5 dBi, 2.4 GHz 4 dBi
- Maximum TX power: 6 GHz 24 dBm, 5 GHz 26 dBm, 2.4 GHz 23 dBm
- Maximum BSSIDs: 8 per radio
- Supported data rates: 802.11be (WiFi 7) 6 GHz 7.3 Mbps to 5.8 Gbps, 5 GHz 7.3 Mbps to 4.3 Gbps; 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps; 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps; 802.11n 6.5 Mbps to 300 Mbps
- Features: Wireless meshing, band steering, 802.11v BSS transition management, 802.11r fast roaming, 802.11k radio resource management, advanced radio management, Passpoint (Hotspot 2.0), captive hotspot portal with custom branding landing page, voucher authentication, payment based authentication, external portal server support, password authentication, guest network isolation, private pre shared key (PPSK), WiFi speed limiting, client device isolation, WiFi schedules, RADIUS over TLS (RadSec), dynamic RADIUS assigned VLAN
- Maximum power consumption: 22W
- Supported voltage range: 42.5 to 57V DC
- Networking interface: 1 x 10 GbE RJ45 port
- Weight: 750 g (1.7 lb)
- Management: Ethernet
- Enclosure material: UV stabilised polycarbonate, aluminium alloy
- Mount material: Stainless steel (SUS304), galvanised steel (SGCC)
- LEDs: System white/blue
- Channel bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
- NDAA Compliant: Yes
- Certifications: CE, FCC, IC
- Ambient operating temperature: -30 to 40° C (-22 to 104° F)
- Ambient operating humidity: 5 to 95% noncondensing
- Colour: White
- Application requirements: UniFi Network version 9.0.114 and later (U7 Pro XG - White)
Note: For installation assistance, you can contact us or reach out directly to the brand.
Package Contents
- Ubiquiti U7 Pro XG Access Point
- Lite Mount
