Description
The Ubiquiti U7 Pro XGS in black is a ceiling mounted 8 stream WiFi 7 access point with a dedicated spectral scanning radio and 10/5/2.5/1 GbE support. From the inside out, every mechanical and electronic detail has been meticulously shaped to strike the perfect balance between aesthetics and performance, with a new thermal architecture enabling the sleekest form factor ever while preserving the timeless look that UniFi fans know and love. In addition to more streams on 5 GHz (4x4), the U7 Pro XGS includes a dedicated radio for advanced interference detection and smarter channel decision making. Equipped with 10 GbE ports to expose the performance potential of WiFi 7, it supports single clients capable of 3+ Gbps throughput. Covering up to 160 m² (1,750 ft²) and supporting over 500 connected devices, it features a 6 GHz radio and is powered using PoE++. By choosing UniFi, you are tapping into a long term ecosystem of innovation, with UniFi Network 9 advancements set to roll out throughout the year bringing next level networking features, intelligence, and analytics. For the first time, the U7 Pro XGS comes in dual colour options, white and this new black variant, blending seamlessly into any interior design. If you are looking to modernise your network with top tier performance and a timeless yet modern look, the U7 Pro XGS ushers you into the new era of WiFi: low latency, high speed, and a true wired experience without the cables.
Features
- 8 spatial stream WiFi 7 with 6 GHz support
- Up to 160 m² (1,750 ft²) coverage
- 500+ connected devices
- 6 GHz radio
- 10/5/2.5/1 GbE uplink
- Powered using PoE++
- Dedicated spectral scanning radio for advanced interference detection and smarter channel decision making
- Sleek form factor with new thermal architecture
Specifications
- Dimensions: Ø215 x 32.5 mm (Ø8.5 x 1.3 inches)
- Colour: Black
- WiFi standard: WiFi 7
- Spatial streams: 8
- Coverage area: 160 m² (1,750 ft²)
- Maximum client count: 500+
- Uplink: 10 GbE
- Mounting: Ceiling, wall (Lite Mount included)
- Power method: PoE++
- MIMO: 6 GHz 2 x 2 (DL/UL MU-MIMO), 5 GHz 4 x 4 (DL/UL MU-MIMO), 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
- Maximum data rate: 6 GHz 5.8 Gbps (BW320), 5 GHz 8.6 Gbps (BW240), 2.4 GHz 688 Mbps (BW40)
- Antenna gain: 6 GHz 6 dBi, 5 GHz 6 dBi, 2.4 GHz 4 dBi
- Maximum TX power: 6 GHz 24 dBm, 5 GHz 29 dBm, 2.4 GHz 23 dBm
- Maximum BSSIDs: 8 per radio
- Supported data rates: 802.11be (WiFi 7) 6 GHz 7.3 Mbps to 5.8 Gbps, 5 GHz 7.3 Mbps to 8.6 Gbps; 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps; 802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps; 802.11n 6.5 Mbps to 600 Mbps
- Features: Wireless meshing, band steering, 802.11v BSS transition management, 802.11r fast roaming, 802.11k radio resource management, advanced radio management, Passpoint (Hotspot 2.0), captive hotspot portal with custom branding landing page, voucher authentication, payment based authentication, external portal server support, password authentication, guest network isolation, private pre shared key (PPSK), WiFi speed limiting, client device isolation, WiFi schedules, RADIUS over TLS (RadSec), dynamic RADIUS assigned VLAN
- Maximum power consumption: 29W
- Supported voltage range: 42.5 to 57V DC
- Networking interface: 1 x 10 GbE RJ45 port
- Weight: 800 g (1.8 lb)
- Management: Ethernet
- Enclosure material: UV stabilised polycarbonate, aluminium alloy
- Mount material: Stainless steel (SUS304), galvanised steel (SGCC)
- LEDs: System white/blue
- Channel bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
- NDAA Compliant: Yes
- Certifications: CE, FCC, IC
- Ambient operating temperature: -30 to 40° C (-22 to 104° F)
- Ambient operating humidity: 5 to 95% noncondensing
- Application requirements: UniFi Network version 9.1.120 and later (U7 Pro XGS - Black)
Note: For installation assistance, you can contact us or reach out directly to the brand.
Package Contents
- Ubiquiti U7 Pro XGS Access Point, Colour Black
- Lite Mount
