Description:
The Standard 24 PoE switch is a 24 port, Layer 2 PoE switch built with a fanless cooling system for quiet, reliable operation. It offers 1 Gbps downlink and uplink speeds, along with PoE output up to PoE+ and a total PoE availability of 95W, making it capable of powering multiple connected devices directly. With a switching capacity of 52 Gbps and a forwarding rate of 39 Mpps, the switch ensures smooth data transmission without bottlenecks.
Features:
- Fanless, silent cooling design
- Compact 1U rackmount form factor
- Switching capacity of 52 Gbps with 39 Mpps forwarding rate
- Supports VLANs, LACP port aggregation, and 802.1X authentication
- IGMP snooping and advanced IGMP configuration
- DHCP snooping and guarding for added protection
- Port mirroring, port isolation, and jumbo frame support
- UniFi AR management for visual port identification via mobile app
Specifications:
- Dimensions: 442 x 200 x 44 mm (17.4 x 7.9 x 1.7 inches)
- Port Layout: 24 GbE RJ45 ports including 16 PoE+ at 1G/100M/10M, 2 1G SFP ports
- Maximum PoE Output: Up to PoE+
- Total PoE Availability: 95W
- Form Factor: Rack mount 1U
- Switching Capacity: 52 Gbps
- Total Non Blocking Throughput: 26 Gbps
- Forwarding Rate: 39 Mpps
- Supported VLANs: 1,000
- MAC Address Table Size: 8,000
- Packet Buffer Size: 0.5 MB
- Layer 2 Features: LACP port aggregation, STP and RSTP, advanced IGMP configuration with querier, fast leave, and router port, IGMP snooping, 802.1X control, MAC based ACLs and device isolation, DHCP snooping and guarding, egress rate limit, flow control, storm control, multicast and broadcast rate limiting, MAC address blocking, IP based ACLs and network isolation, MAC based port restriction, port isolation, port mirroring, jumbo frames, LLDP-MED, voice VLAN, loop protection
- PoE Ports: 16 PoE+ ports
- Maximum PoE Wattage per Port: PoE 15.4W, PoE+ 32W
- Maximum Power Consumption: 25W excluding PoE output, 120W including PoE output
- Power Method: Universal input, 100 to 240V AC, 50/60 Hz
- Power Input Method: AC input
- Power Supply: AC/DC, internal, 120W
- Supported Voltage Range: 100 to 240V AC
- Management: Ethernet, AR
- Heat Dissipation Excluding PoE Output: 85.3 BTU/hr
- Weight Without Mounting Brackets: 3 kg (6.6 lb)
- Weight With Mounting Brackets: 3.1 kg (6.8 lb)
- Enclosure Material: SGCC steel
- Mount Material: SGCC steel
- Supported Rack Depth: 400 to 1200 mm (15.7 to 47.2 inches)
- LCM Display: 1.3 inch touchscreen
- ESD/EMP Protection: Air plus or minus 16kV, Contact plus or minus 12kV
- Operating Temperature Range: Minus 5 to 40 degrees Celsius (23 to 104 degrees Fahrenheit)
- Operating Humidity Range: 10 to 90 percent, noncondensing
- Certifications: CE, FCC, IC
- NDAA Compliance: Yes
