Description
The Ubiquiti UniFi Indoor Cable Cat6A CMP is a Category 6A Ethernet cable for high speed deployments in environments that require plenum rated cabling. This Category 6A UTP communications multipurpose cable features a plenum (CMP) rated, fire resistant jacket made of flame retardant polyvinyl chloride, along with an anti crosstalk divider for signal integrity. Supplied in a 305 m (1,000 ft) length with solid bare copper 23 AWG conductors and four twisted colour coded pairs, it also includes a ripcord for easy jacket removal during installation.
Features
- Category 6A UTP communications multipurpose cable
- Plenum (CMP) rated, fire resistant jacket
- Anti crosstalk divider
- Cable length 305 m
- Solid bare copper conductors
- Ripcord included
Specifications
- Length: 305 m (1,000 ft)
- Type: Category 6A
- Flame rating: CMP
- Operating environment: Indoor
- Box dimensions: 494 x 302 x 481 mm (19.4 x 11.9 x 18.9 inches)
- Box weight: 21.3 kg (47 lb)
- Jacket Colour: White
- Jacket diameter: 6.7 ±0.2 mm
- Jacket material: Flame retardant polyvinyl chloride (FRPVC)
- Shielding type: UTP
- Conductor type: Solid bare copper
- Conductor wire gauge: 23 AWG
- Bend radius: Minimum 26.8 mm (1.05 inches)
- Twisting: 4 twisted pairs with colour code; Pair 1 white-blue / blue, Pair 2 white-orange / orange, Pair 3 white-green / green, Pair 4 white-brown / brown
- Anti crosstalk divider: Yes
- Ripcord: Yes
- Electrical transmission standards: ANSI/TIA-568.2-D, ISO/IEC 11801-1 (Edition 2.2), IEC 61156-5 (Edition 2.1)
- Flame test: NFPA 262 (CMP)
- Material and construction: UL 444, CSA 22.2 NO.214, EU Directive 2011/65/EU (RoHS2), EU Directive 2006/95/EC (LVD)
- Installation temperature: 0 to 60° C (32 to 140° F)
- Ambient storage temperature: -20 to 75° C (-4 to 167° F)
- Ambient operating temperature: -20 to 75° C (-4 to 167° F)
Package Contents
- Ubiquiti UniFi Indoor Cable Cat6A CMP
