Description
The Ubiquiti UniFi Premium Patch Cable Outdoor is an ultra thin, rugged, shielded outdoor patch cable, designed and optimized to perform in the harshest environments for 10 GbE networking. It features shielded RJ45 connectors, an insulated, weatherproof jacket, and internal foil shielding with a drain wire for increased ESD damage protection. With a 3.9 mm outer diameter for this 12 m length, the cable is built with a thermoplastic elastomer jacket, F/UTP shielding, and stranded copper conductors, offering UV resistance to ISO4892-2 and support for PoE types up to PoE+++.
Features
- Shielded RJ45
- Insulated, weatherproof jacket
- Internal foil shielding and drain wire for increased ESD damage protection
- 3.9 mm outer diameter for 12 to 15 m lengths
- Length: 12 m
- Designed and optimized for 10 GbE networking in the harshest environments
Specifications
- Available lengths end to end: 1, 2, 3, 5, 8, 12, 15 m (3.3, 6.6, 9.8, 16.4, 26.2, 39.8, 49.2 ft)
- Available Colours: White, black
- Pack options: Single unit
- Supported data rate: 10G
- Supported PoE type: Up to PoE+++
- Connector: 2 frosted booted and shielding RJ45
- Operating environment: Outdoor
- Jacket diameter: 1 to 8 m: 3.5 mm (0.14 inches); 12 to 15 m: 3.9 mm (0.15 inches)
- Jacket material: Thermoplastic elastomer (TPE)
- Shielding type: F/UTP
- Conductor type: Stranded copper
- Conductor wire gauge: 1 to 8 m (3 to 26 ft) 34 AWG; 12 to 15 m (39 to 49 ft) 32 AWG
- Bend radius: 1 to 8 m minimum 28 mm (1.1 inches); 12 to 15 m minimum 31 mm (1.22 inches)
- UV resistance: ISO4892-2
- Flame rating: VW-1 (UL1581)
- Standards: TIA/EIA-568-B.2, ISO/IEC 11801
- Installation temperature: -20 to 60° C (-4 to 140° F)
- Ambient storage temperature: -40 to 85° C (-40 to 185° F)
- Ambient operating temperature: -20 to 60° C (-4 to 140° F)
Package Contents
- Ubiquiti UniFi Premium Patch Cable Outdoor
